Mini Low Speed Electric Pickup for Transportation

The Mini Low Speed Electric Pickup for Transportation is a compact, low-speed electric mini-truck designed for urban short-distance transportation and logistics. It features a small footprint and excellent maneuverability, making it well-suited for navigating narrow city streets and congested urban environments. This electric mini-truck is a sustainable and efficient solution to meet various logistics needs.

Send Inquiry

Product Description

Key Features:

Compact Design: The Mini Low Speed Electric Pickup's small size makes it perfect for zipping through busy urban areas and easily parking in tight spaces, enhancing operational convenience.

Electric Power: Using an electric power system, this vehicle produces zero emissions, making it environmentally friendly and reducing air pollution.

Low-Speed Performance: This small pickup is designed specifically for low-speed urban transportation, suitable for city streets with speed restrictions, reducing the risk of accidents.

Versatile Applications: The Mini Low Speed Electric Pickup is suitable for a variety of purposes, including small-scale cargo transport, urban cleaning tasks, warehouse handling, and short-distance transportation within the city.

Efficient Operations: Low operating costs, minimal maintenance expenses, and relatively low charging costs provide an economical solution.

Eco-Friendly Materials: The use of renewable and recyclable materials reduces environmental impact, contributing to sustainability.

Comfortable Riding Experience: Spacious seating ensures the comfort of both the driver and passengers.

Safety Features: The Mini Low Speed Electric Pickup is equipped with basic safety features, including a braking system, lighting system, and seat belts, ensuring road safety.

The Mini Low Speed Electric Pickup for Transportation is a versatile, eco-friendly, and compact electric vehicle that offers a sustainable and efficient solution for urban logistics and transportation needs. Its small footprint and eco-friendly characteristics make it an ideal choice for adapting to modern urban living. Whether used for commercial transportation or urban cleaning tasks, this electric mini-truck will meet your requirements.

Parameter configuration

Vehicle status	72V 4KW	72V 5KW
Right hand drive	○	○
Length×Width×Height (mm)	3475×1375×1550	3475×1375×1550
Container internal dimensions	1620X1245X300	1620X1245X300
Wheelbase (mm)	2315	2315
Front track (mm)	1195	1195
Rear track (mm)	1185	1185
Front suspension (mm)	455	455
Rear suspention (mm)	705	705
Curb weight (kg)	710	710
Load quality (kg)	500	500
Seats No.	2	2
Gross weight (kg)	1340	1340
Performance parameters
Max speed (km/h)	40	40
Acceleration time s (0-40km)	15	15
Max grade	0.25	0.25
Min turning diameter (m)	≤9	≤9
Maximum angle	36.3(outer wheel）/42(inner wheel）	36.3(outer wheel）/42(inner wheel）
Approach angle (°)	≥55	≥55
Departure angle (°)	≥35	≥35
Bauchfreiheit (mm, no load)	≥150	≥150
Body structure
Cab	Integral sheet metal	Integral sheet metal
Tube doors	-	-
Cargo box（bed）	Triple folding gate	Triple folding gate
Battery/motor parameters
Battery type	Maintenance-free lead-acid batteries	Maintenance-free lead-acid batteries
Battery specification(V/Ah）	72V ,100Ah	72V ,100Ah
Battery optional	○ 105Ah LFP ○ 240Ah LFP	○ 105Ah LFP ○ 240Ah LFP
Lithium electric heating plate	○	○
Range (no load) (km)	≥120	≥120
220V charging plug	●	●
110~220V charging plug (wide voltage)	○	○
Charging time (20%-100%) (h)	8~10	8~10
Motor type	AC asynchronous motor	AC asynchronous motor
Rated power (kW)	4KW	5KW
Chassis/Wheel Braking
Drive form	RWD	RWD
Front suspension	Double wishbone coil spring independent suspension	Double wishbone coil spring independent suspension
Rear suspension	Vertical leaf spring (5 pieces)	Vertical leaf spring (5 pieces)
Drive axle	Integral (speed ratio 12.76)	Integral (speed ratio 12.76)
Front brake	Disc	Disc
Rear brake	Drum	Drum
Rim	12X4B（steel）● 12X4.0 (aluminum)○	12X4B（steel）● 12X4.0 (aluminum)○
Tire	145 R12LT（radial tire）● 5.00-12ULT (dirt tires)○	145 R12LT（radial tire）● 5.00-12ULT (dirt tires)○
power-assisted steering	○	○
Brake assist	●	●
Inside/outside configuration
Door lock	Manual	Manual
Window	Manual	Manual
Front Seat	Primary/Secondary Independent Seats	Primary/Secondary Independent Seats
Rear seat	-	-
Seat headrest	○	○
Jump seats	○	○
AC	○	○
Towing	○	○
Front receiver	-	-
Interior rear view mirror	●	●
Instrument	Metric● British○	Metric● British○
Front searchlight	○	○
Roof spotlight	-	-
AVS Sound Module	○	○
Side retro reflector	●	●
Red reflective stickers	○	○
Seat belt	●	●
Seat belt certification	DOT● Emark○	DOT● Emark○
Reverse image	●	●
Mp5	7“MP5● Korean language○ Russian language○	7“MP5● Korean language○ Russian language○
Fender extensions	-	-
Car cover	○	○
Child lock	-	-
Front bumper	○	○
Rear bumper	-	-
Pedal rack	-	-
Roll cage	-	-
Spare tire	-	-
Charger plug	China standard● American standard○ European Standard○ British standard○ Italian standard○	China standard● American standard○ European Standard○ British standard○ Italian standard○
VIN	●right/○left	●right/○left
Spray wax	○	○
Swatches	●	●
Rubber Liner	○	○

Note In addition to white, red, yellow do not add money, other colors for special colors need to add 300 RMB, charger plug if not the national standard will make up the difference, the difference in 20-100 RMB

"-" indicates that this configuration is not available. "○" represents optional items, which need to be selected and explained; ● Indicates the standard configuration item.
