4 Seat Electric Mini Pickup Truck
  • 4 Seat Electric Mini Pickup Truck4 Seat Electric Mini Pickup Truck

4 Seat Electric Mini Pickup Truck

We are proud to introduce our 4 seat electric mini pickup truck, a cutting-edge electric transportation solution that offers exceptional performance, eco-friendliness, and versatility. This electric mini pickup truck is renowned for its outstanding electric powertrain and multifunctional design, making it an ideal companion for both urban and rural lifestyles.

Send Inquiry

Product Description

Key Features:

Electric Drive System: Our electric mini pickup truck is equipped with a top-tier electric drive system that provides emission-free transportation, reducing your carbon footprint and contributing to the planet's well-being.

Four Seats: Four seats mean you can travel with family, friends, or colleagues, sharing enjoyable journeys without worrying about cramped seating space.

Multifunctional Design: Our mini pickup truck's design caters to various purposes, adapting to different work and leisure needs. The rear seats can fold down to offer additional cargo space for accommodating large items or transport equipment.

High-Performance Battery: Powered by robust battery technology, our electric mini pickup truck offers extended range capabilities, allowing you to confidently reach your destinations without frequent recharging.

Modern Exterior: With a stylish and contemporary exterior design, your vehicle not only provides comfort on the road but also turns heads in urban streets and suburban environments.

Safety: Our mini pickup truck is equipped with advanced safety features such as Anti-lock Braking System (ABS), Electronic Stability Control (ESC), and airbags to ensure your optimal protection on the road.

Smart Connectivity: Built-in smart entertainment and navigation systems help you stay connected and find the best routes, offering an exceptional driving experience.

Sustainability: We are committed to sustainable transportation, and this electric mini pickup truck is our pledge to contribute to environmental preservation.


This 4 seat electric mini pickup truck represents the future of travel, ideal for daily commuting, shopping, or adventure. It seamlessly blends electric technology, multifunctionality, and modern design to provide an exceptional driving experience. Choose our electric mini pickup truck, and you'll experience a green, efficient, and versatile future of transportation.


Parameter configuration

Model ID

KK1121S10

Vehicle status

73.6V 10.5KW

Right hand drive

Length×Width×Height (mm)

3850X1510X1845

Container internal dimensions

900X1315X400

Wheelbase (mm)

2520

Front track (mm)

1315

Rear track (mm)

1315

Front suspension (mm)

455

Rear suspention (mm)

705

Curb weight (kg)

1015

Load quality (kg)

150

Seats No.

4

Gross weight (kg)

1325

Performance parameters



Max speed (km/h)

80

Acceleration time s (0-40km)

20

Max grade

0.35

Min turning diameter (m)

≤11

Maximum angle

30(outer wheel)/32(inner wheel)

Approach angle (°)

≥55

Departure angle (°)

≥35

Bauchfreiheit (mm, no load)

≥200

Body structure



Cab

Integral sheet metal

Tube doors

Cargo box(bed)

Rear side

Battery/motor parameters



Battery type

LFP battery

Battery specification(V/Ah)

73.6V,240Ah

 Battery optional

-

 Lithium electric heating plate

Range (no load) (km)

≥200

220V charging plug

-

110~220V charging plug (wide voltage)

 Charging time (20%-100%) (h)

6~8

Motor type

AC asynchronous motor

Rated power (kW)

10.5KW

Chassis/Wheel Braking



Drive form

RWD/4WD

Front suspension

Double wishbone coil spring independent suspension

Rear suspension

Vertical leaf spring (3 pieces)

Drive axle

Front axle 8.5/15
 Rear axle 8.25

Front brake

Disc

Rear brake

Drum

Rim

15X5.5J(steel)●
15×6.0J(aluminum)○

Tire

195/65 R15(radial tire)●
195/65 R15  (dirt tires)○

power-assisted steering

Brake assist

Inside/outside configuration



Door lock

Electric

Window

4 doors electric

Front Seat

Four-way adjustable, with headrest, with map pocket

Rear seat

Bench seat, foldable, with headrest

Seat headrest

front●/rear●

Jump seats

-

AC

Towing

Front receiver

Interior rear view mirror

Instrument

Metric●
British○

Front searchlight

Roof spotlight

AVS Sound Module

Side retro reflector

Red reflective stickers

Seat belt

front●/rear○

Seat belt certification

DOT●
Emark○

Reverse image

Mp5

7“MP5●
Korean language○
Russian language○

Fender extensions

Car cover

Child lock

Front bumper

larger light holder●

Rear bumper

Pedal rack

Roll cage

Spare tire

Charger plug

China standard●
American standard○
European Standard○
British standard○
Italian standard○

VIN

●right/○left

Spray wax

Swatches

Rubber Liner


Note In addition to white, red, yellow do not add money, other colors for special colors need to add 300 RMB, charger plug if not the national standard will make up the difference, the difference in 20-100 RMB

"-" indicates that this configuration is not available. "○" represents optional items, which need to be selected and explained; ● Indicates the standard configuration item.
